4 Channel HMA MM OM3 5' - FIBERFOX
The FIBERFOX 4CH Cable connector is an expanded beam hermaphroditic connector suited for a vast array of applications, including Lighting, Network, PA, Video, Broadcast, Defense & Government, Railway and Petrochemical. The innovative design ensures its ability for deployment in the toughest environments where constant performance and total reliability are critical. The connector is designed according to the MIL-DTL-83526 standard and is compatible all other connectors which use this standard. Neutrik offers this extraordinary connector solution in singlemode and multimode.
Benefiting from the expanded beam technology and the precision optical alignment the system creates high immunity against dust, mud, liquids and other contaminations. The FIBERFOX hermaphroditic coupling eliminates the need for adaptors and female and male mating halves. The cable connector comes pre-assembled and is not available as a single component. The finished cable is available in standardized lengths and is packed either on a drum or an airspool.
Email a Friend
Stock Notice
Not enough Inventory? Submit your email address and desired total quantity below, and we will notify you when stock arrives.
| Cable | 4-Strand Multi-Mode OM3 Tactical |
| Boot | Rubber (EPDM) |
| Insert | Steel |
| Shell | Aluminium |
| Shell Plating | Hard anodize |
| Strain relief | Brass |
- Available in multimode and singlemode
- Wear-free connectors, > 10.000 mating cycles without any maintenance
- Cables are prolongable direct, no couplers required
- Heavy-duty, connectors IP68 (even unprotected)
| Tensile Strength | 1800 N |
| Compressive load | 50,000N |
| Free Fall Resistance | 500 falls onto concrete from 1.2M height |
| Lifetime (typ.) | >10000 mating cycles |
|
Insertion loss MM
Insertion Loss Singlemode
|
Typ. 1.5dB per connection / Max. 2.5dB per connection
Typ. 1.0 dB max. 2.0 dB per connection
(according with IEC 61300-3-4) Max. 2.5dB per connection (acc. with IEC
61300-3-34) |
| Compatibility | MIL-DTL-83526 |
| Optical wiringISO / IEC 11801 | ISO / IEC 11801 |
